Type: Plate
Standard: ASTM A588
Steel Plate Specification: Thickness:<=200mm
Application: A588 GrC Weather resisting steel intended primarily for use in welded bridges and buildings where savings in weight or added durability are important.
Packaging Details: 2 tons per wooden box with pallet
Delivery Detail:20-25 days
A588 GrC Weather resisting steel Typical Chemical Requirements(%)
Type | C | Mn | P | S | Si | Cr | Ni | Cu | V |
A588 GrC | 0.15 | 0.80-1.35 | 0.04 | 0.05 | 0.15-0.40 | 0.30-0.50 | 0.25-0.50 | 0.20-0.50 | 0.01-0.10 |
A588 GrC Weather resisting steel Steel Mechanical Test Requirements(%)
Type | Tensile Strength, min | Yield Strength, min | Elongation in 2 in.or 50mm, min, % | Hardness, max |
ksi | MPa | ksi | Mpa | HB | HRB | HV |
A588 GrC | 63 | 435 | 42 | 290 | 21 | | | |
Type: Plate
Standard: ASTM A588
Steel Plate Specification: Thickness:<=200mm
Place of Origin: Henan China (Mainland)
Brand Name: SDJS
Application: A588 GrC Weather resisting steel intended primarily for use in welded bridges and buildings where savings in weight or added durability are important.
Packaging Details: 2 tons per wooden box with pallet
Delivery Detail:20-25 days
A588 GrC Weather resisting steel Introduction： The atmospheric corrosion resistance of this steel in most environments is substantially better than that of carbon
structural steels with or without copper addition .
A588 GrAC Weather resisting steel Usage：When properly exposed to the atmosphere, this steel is suitable for many applications in the bare (unpainted) condition.
A588 GrC Weather resisting steel Typical Chemical Requirements(%)
Type | C | Mn | P | S | Si | Cr | Ni | Cu | V |
A588 GrC | 0.15 | 0.80-1.35 | 0.04 | 0.05 | 0.15-0.40 | 0.30-0.50 | 0.25-0.50 | 0.20-0.50 | 0.01-0.10 |
A588 GrC Weather resisting steel Steel Mechanical Test Requirements(%)
Type | Tensile Strength, min | Yield Strength, min | Elongation in 2 in.or 50mm, min, % | Hardness, max |
ksi | MPa | ksi | Mpa | HB | HRB | HV |
A588 GrC | 63 | 435 | 42 | 290 | 21 | | | |
Type: Plate
Standard: ASTM A588
Steel Plate Specification: Thickness:<=200mm
Place of Origin: Henan China (Mainland)
Brand Name: SDJS
Application: A588 GrC Weather resisting steel intended primarily for use in welded bridges and buildings where savings in weight or added durability are important.
Packaging Details: 2 tons per wooden box with pallet
Delivery Detail:20-25 days
A588 GrC Weather resisting steel Introduction： The atmospheric corrosion resistance of this steel in most environments is substantially better than that of carbon
structural steels with or without copper addition .
A588 GrAC Weather resisting steel Usage：When properly exposed to the atmosphere, this steel is suitable for many applications in the bare (unpainted) condition.
A588 GrC Weather resisting steel Typical Chemical Requirements(%)
Type | C | Mn | P | S | Si | Cr | Ni | Cu | V |
A588 GrC | 0.15 | 0.80-1.35 | 0.04 | 0.05 | 0.15-0.40 | 0.30-0.50 | 0.25-0.50 | 0.20-0.50 | 0.01-0.10 |
A588 GrC Weather resisting steel Steel Mechanical Test Requirements(%)
Type | Tensile Strength, min | Yield Strength, min | Elongation in 2 in.or 50mm, min, % | Hardness, max |
ksi | MPa | ksi | Mpa | HB | HRB | HV |
A588 GrC | 63 | 435 | 42 | 290 | 21 | | | |
