Grade: 300 Series Steel
Type: Plate, Pipe/Tube, Coil
Standard: ASTM A240, JIS G4350
Steel Plate Specification: Thickness:0.3mm-100mm, Width:200-3000mm.
Place of Origin: Henan China (Mainland)
Brand Name: SDJS
Application: SUS304LN Stainless Steel is used for a wide variety of home and commercial applications.
Surface treatment: No.1,2B,BA,No.4,Mirror, HL,or as customers' requirements
SUS304LN Stainless Steel Introduction
SDJS SUS304LN stainless is a nitrogen-strengthened version of Carpenter Stainless Type SUS304L. By means of solid solution strengthening, the nitrogen provides significantly higher yield and tensile strength as annealed than Type SUS304L without adversely affecting ductility,corrosion resistance or non-magnetic properties. In the hot rolled unannealed condition, yield strengths of 75 ksi (515 MPa) or higher can be achieved for bar diameters up to 1.375 in. (34.925 mm).
SUS304LN Stainless Steel Usage
Magnetic resonance imaging (MRI) scanners, reinforcing bar for structures surrounding MRI scanners, pressure vessels, cryogenic applications.
SUS304LN Stainless Steel Typical Chemical Requirements(%)
|
Type
|
C
|
Si
|
Mn
|
P
|
S
|
Ni
|
Cr
|
Mo
|
Cu
|
N
|
Other
|
|
SUS304
|
≤ 0.08
|
≤ 1.00
|
≤ 2.00
|
≤ 0.045
|
≤ 0.030
|
8.00--10.50
|
18.00--20.00
|
--
|
--
|
--
|
--
|
|
SUS304L
|
≤ 0.030
|
≤ 1.00
|
≤ 2.00
|
≤ 0.045
|
≤ 0.030
|
9.00--13.00
|
18.00--20.00
|
--
|
--
|
--
|
--
|
|
SUS304N1
|
≤ 0.08
|
≤ 1.00
|
≤ 2.50
|
≤ 0.045
|
≤ 0.030
|
7.0--10.5
|
18.00--20.00
|
--
|
--
|
0.10--0.25
|
--
|
|
SUS304N2
|
≤ 0.08
|
≤ 1.00
|
≤ 2.50
|
≤0.045
|
≤ 0.030
|
7.50--10.50
|
18.00--20.00
|
--
|
--
|
0.15--0.30
|
Nb≤ 0.15
|
|
SUS304LN
|
≤ 0.030
|
≤ 1.00
|
≤ 2.00
|
≤ 0.045
|
≤ 0.030
|
8.50--11.50
|
17.00--19.00
|
--
|
--
|
0.12--0.22
|
--
|
SUS304LN Stainless Steel Mechanical Test Requirements(%)
|
Type
|
Yield Strength(MPa)
|
Tensile Strength(MPa)
|
Elongation(%)
|
Hardness, max
|
|
HB
|
HRB
|
HV
|
|
SUS304
|
≥ 205
|
≥ 520
|
≥ 40
|
≤ 187
|
≤ 90
|
≤ 200
|
|
SUS304L
|
≥ 175
|
≥ 480
|
≥ 40
|
≤ 187
|
≤ 90
|
≤ 200
|
|
SUS304N1
|
≥ 275
|
≥ 550
|
≥ 35
|
--
|
≤ 95
|
≤ 220
|
|
SUS304N2
|
≥ 275
|
≥ 550
|
≥ 35
|
--
|
≤ 95
|
≤ 220
|
|
SUS304LN
|
≥ 245
|
≥ 550
|
≥ 40
|
≤ 217
|
≤ 95
|
≤ 220
|
Te.l: 8-6-3715.5031185
Fa.x: 8.6-3718.6220366
Mobile:8.6-138.03905272
m.ai.l: sdjs|@|firsteelplate.|com
Product Tags:
|
|
SUS304LN Stainless Steel Images
|
